Fanless embedded NUC BoxPC-R2312 with AMD Ryzen™ Embedded R2312 CPU / BSNPDEA1
The fanless industrial
BoxPC BSNP-NUCR-R2312 is designed according to the
embedded NUC™ standard and is based on the
AMD Ryzen™ Embedded R2000 platform.
This is characterised by good efficiency, reliability, balanced performance and a powerful integrated graphics unit (
Radeon™ Vega 3).
Fanless / low-maintenance / noiseless / robust / long-term availability - BoxPCs of the BSNP series - Made in Germany
The
AMD Ryzen™ Embedded R2312 CPU is a further development of the successful predecessor model AMD Ryzen™ Embedded R1505G.
Compared to this, the CPU and GPU clock rates have been increased and the CPU is based on the Zen+ (12nm) processor microarchitecture (instead of Zen / 14nm)
The BoxPC-NUCR-R2312 is perfectly suited for use as a reliable industrial computer in a wide range of applications thanks to its long-term embedded CPU and its numerous interfaces and fanless, maintenance-free housing:
- Industrial PC in automation / measurement technology / machine controls / control technology
- Retail: POS systems (point of sale), kiosk systems, vending machines, deposit return systems, digital signage
- Imaging applications (2x 4K display output)
- Industrial control and automation
- IoT gateways / cloud / fog computer
- Aviation and defence
- Digital casino games / slot machines
- Media and collaboration / embedded media & collaboration
- Workstation computers / thin client / lean client in corporate IT
- Robotics, mobile systems (automotive grade power supply), robotics in retail, autonomous mobile robots (AMR)
- BOS (authorities and organisations with security tasks)
- Medical technology applications: Clinic & practice management, eAnamnesis
The NUCD BoxPC features a wide input voltage range from 8 VDC to 32 VDC as well as a special pre-fitting for vehicle use
, including an input for continuous plus (terminal 30) and ignition plus (terminal 15). In addition, a special overvoltage protection circuit is implemented, which takes load-dump scenarios into account in particular.
Developed and manufactured in Germany - for industrial applications in harsh environments.
The following CPU is used with a configurable cTDP of 12W - 25W:
AMD Ryzen™ Embedded R2312 - 2 Cores / 4 Threads - 2.7 GHz to 3.5 GHz
AMD Radeon™ Vega 3 Graphics (1.2 GHz)
With a large number of powerful interfaces in a small space, the system is prepared for use in many applications.
These interfaces include mDP, USB 3.1 Gen2 (10Gb/s), M.2 socket for SATA or NVMe / USB, microSD card socket.
Further information can be found in the ‘Technical data’ tab.
Modularly expandable:
Expand your system with various interface options:
The rear USB port is designed, among other things, to connect the EM-I/O interface modules. This allows the BoxPC-NUCR to be expanded with interfaces such as CAN, GPIO, relays, LTE/UMTS, etc..
More information can be found on our manufacturer's website: EM-I/O Modules
