TPS100-GP24V - DIN Rail Power Supply

Product No.:: TPS100-24V
Shipping time:: ca. 3-5 days (abroad may vary)
Stock:: 2 pieces

Please log in to purchase products

Add to wish list

Description

TPS100-GP24V - Green Power / 100W 24V

Perfectly suitable for TB-M and industrial BoxPCs from E.E.P.D. GmbH

The TPS100-GP24V is a powerful electronic switching power supply for top hat rail mounting (DIN rail power supply).
It is suitable e.g. B. for home automation (smart home systems) or industrial applications (automation, mechanical engineering, etc.)
As a model of the GREEN POWER series, it is characterized by extremely low standby consumption (<0.3W).
Due to its design, the power supply unit is not only suitable for top hat rail mounting like some other models, but also for installation in house fuse boxes / electrical distribution boxes.

The screw connections ensure a simple connection, the output voltage is adjustable (24 - 28 V), the device is preset to 24 V for you.

PROPERTIES:

top hat rail power supply, stabilized
24 VDC, 2.5 A, xx W max.
24 - 28 V infinitely variable by potentiometer
Low ripple 1 % Output (V)
100 % full load Burn-In test
Standby mode < 0.3 W
Dimensions: 91 x 90 x 57mm (L x W x H)

Technical data

SAFETY FEATURES:

Over voltage protection
Overload protection, with continuous power limitation (no simple Hiccup solution)
Over current protection
Temperature protection
Short circuit protection
Protection class II
Protection IP 30

SAFETY STANDARDS:

EN61000-3-2
EN61347-2-13
CE,
RoHS

EMC:

EN61204-3, EN55022 B, EN55011 B, EN61000-6-2, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11

EMI:

FCC-B, CISPR22-B

MOUNTING:

Din-Rail TS 35/7.5 or TS 35/15 and standard home fuse boxes and electrical distribution boxes

DIMENSION:

91 x 90 x 57 mm (L x W x H )

This product is compatible with (for example):

TB-M - BoxPC - modular industrial PC

Tough-Box-Modular / TB-M
Fanless, modularly expandable industrial PC (24/7 IPC)
TDP 15W | AMD Embedded G-Series SOC with clock rates of 4 x 1.5 GHz
